Products >> FLEXIBLE HOSES

__________________________________________________________TISTAM____
 MATERIALS:
St.St. AISI 321 ( standard weight, code, n. SP.T.9700.27) – AISI 316 L on application other qualities of st.st.

COVERINGS:
SP.T.9700 tube without cover ( n. braid 0)
SP.T.9750 covered with one braid in st.st. AISI 304. Braid in AISI 321 can be supplied
SP.T.9755 covered with two braids in st.st. AISI 304. on application
SP.T.9740 covered with one braid in galvanized steel.
SP.T.9756 covered with one braid in st.st. AISI 304 and further braid (or strip) in asbestos.


On request:
-Protection with a further SP hose of larger diameter (DOUBLE CONDUIT)

TEMPERATURE:
AISI 321 : -269° C ÷ 800° C
AISI 321 L : -269° C ÷ 800° C

FEATURES:
The good flexibility and the high pressure capability of the type SP.T.9750, together with
its good capacity to absorb vibrations, offer the user an economical and long-lasting
solution to overcome those problems deriving from a dynamic offset or from cyclic motion.

FITTINGS:
Of any type in carbon steel, malleable cast iron, brass, bronze, stainless steel, or
combination of stainless steel and carbon steel. Attachments can be made by electro-
welding (type EL), brazing (type BA and Bf), reusable fittings, etc.



USE:
Wherever very severe ambient conditions are combined with chemical aggressively, high
temperature pressure or vacuum, frequent movement, static or dynamic offset, vibration,
permeability (rare gasses), etc.

MILL LENGTHS
depending on diameters. Indefinite lengths (obtained by argon-arc-Welding) can be supplied on applicatio.
